Complete control system and visualization of the offices in a commercial building in Erbil - Iraq
A commercial building is located in Erbil - Iraq . The building contains two floors with several offices.
Control system Tecomat Foxtrot takes care about control of all functions related all systems in offices like lighting, shutters, sound system ,door access and CCTV system .
Control System:
Foxtrot system is responsible management and interfacing with next electrical systems in offices:
- Lightning: In each office there is many lighting candles and spot lights.
In easy way the user can set required light from different places by touch glass panels or phone/tablet.
- Shutters: Foxtrot allows user to control with all shutters in offices separately, and gives user special functions to control with shutters according to groups related to floors.
- Doors access: Those tow floors have many doors that some of it important and not anyone can access it, Foxtrot allows user to control with all doors by RF cards each employee has card and each one has ID the user reads the card RFID by the reader, fills in his personal information, chooses the doors which can access it, and finally all this information stores in a Data Base.
- Sound system: Teco PLC integrate with DENON Mixer over IP, that allows user to control the sounds by choosing the sources of the sounds, choosing the volume value, and mixing it with DENON in easy way.
- CCTV system: This two floors contain number of cameras to monitor the office and employee. Thanks to Internet programming library provided by Mosaic environment, we get full access to Digifort API
User interface:
Via web maker tool in Mosaic development environment, Foxtrot provides kindly user interface for all previous control functions.
Controlling interface |
Doors access interface |
