Basic features...
• The central unit is designated for installations with CFox and RFox peripheral systems.
• CP-1001 differs from CP-1000 by bigger memory for the user program (up to 384 kB).
• The central module is equipped with 4 universal inputs, 2 inputs 230VAC, and 2 relay outputs.
• Universal inputs can be configured either as an analog input for RTD sensors Pt1000, Ni1000, or NTC thermistors 12 k? or potential-free inputs (dry contacts).
• Binary inputs 230VAC are used for connection of load management signal and main monitoring
• Standard relay outputs 250VAC/3A
• I/O number can be extended by the connection of up to 10 peripheral modules via TCL2 serial bus (345 kbit/s).
• Memory can be expanded by SD/SDHC cards up to 32GB (FAT32 file system).
• Built-in clocks and calendar (RTC)
• The central unit contains 2 CIB bus masters. It allows us to connect up to 64 input and output CFox modules in any combination of I/O and mechanical construction.
• CIB ensures power supply for these peripheral modules too.
• Number of CIB branches is extendable up to 10 using CF-1141 communication modules (connected to TCL2 bus). It means a maximum number of 320 peripheral modules per CPU.
• Optionally 4 RFox communication masters RF-1131 can be connected instead of CF-1141. RFox represents a wireless peripheral system (868MHz).
• The external masters CF-1141 (CFox) and RF-1131 (RFox) can be combined up to a total amount of 4 modules per CPU.
• The serial channel RS-232 is a standard part of equipment and it is used for direct communication with GSM modems and SMS notifications.
• Other channel CH2 allows us to insert an optional communication interface or I/O sub-module.
• Programming and communication (LAN, WiFi, WAN, internet) via Ethernet port. IP addresses can be either static or assigned from DHCP.
• Support of standard protocols like Modbus RTU/TCP (master and/or slave), BACnet (slave only) many others.
• Built-in web server, free creation of user web pages, use file system on SD/SDHC card (XML technology)
• It allows us to create a website of any controlled object.
• It is possible to use it as a programmable converter of communication protocols.
• It is possible to use as a datalogger for any measured value or internal parameter with a time stamp.
• A compact form-factor design suitable for the installation into electrical switchgear/cabinets. The module is mounted on a DIN rail.
• The central module is powered from 24VDC. While using a 27.2V power supply it is possible to use lead accumulators to keep the whole system supplied whereas the time depends on the capacity of the accumulator used.
• It is dedicated to both common and specific control tasks in home and building automation and for the integration with other systems via communication interfaces.
• The module can be programmed in the Mosaic development environment.
