Basic features...
• Module is an actuator with 6 independent outputs (channels) for proportional control of power LED lights or lights with LED chips connected in serial. They are controlled by control of the current.
• Each channel is independently addressed and controlled in range 0 up to 100% of the current range.
• Module can be switched by button into manual mode, so each output can be independently switched on and o? by button.
• Status and error/operation is indicated by an LED on the module
• CIB bus is connected to screw terminals.
• Outputs are connected to a removable screw connector. During designing the wiring, the load of each terminal has to be taken into account
• Module is used for assembly on DIN rail in switchboards.
