BMS system in Islamic Affairs Building - UAE Implemented by: Orient Company . UAE |
 |
|
An administrative building with several cooling & heating systems Our mission is to produce simple interfaces to monitor & control all those systems. |
 |
 |
|
|
FCU system: - In this building, there are many FCUs that can be controlled by our thermostats located in different places of the building, or they can be controlled & monitored with our easy-to-use interfaces. |
 |
|
- Monitoring is done through interfaces specifically designed to be easy to use on the SCADA Reliance system. All thermostats show in a single window. |
|
 |
|
|
|
|
|
Chillers system: - In this project, there are two chillers, 3 primary pumps, 3 secondary pumps, temperature sensors, and DPS switches. |
|
|
|
|
|
FAHU monitoring: -monitor the FAHU elements such as Supply Fan, Extract fans, HRW, cooling valve, and in/out air filters |
|
|
|
|
|
Generator & elevator: -Our mission is to show the status of the 5 lifts that existed in the building. The states that are monitored are: cabin alarm, trip status, fire alarm interlock , as well as Diesel Generator status |
 |
 |
|
|
other systems: It contains the rest systems that existed in the building such as: ♦ smoke and makeup fans ♦ transfer pumps ♦ fire alarm panel and firefighting system ♦ ATS ♦ LV panel ♦ emergency lights. |
 |
 |
|
